DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

Xiangjing (Shanghai) M&E Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

  • 1
  • 2
  • 3

Brand Name : DH-ROBOTICS

Model Number : DH-3

Certification : CE CO

Place of Origin : Chinese

MOQ : one set

Price : 3000usd/set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 999 sets /month

Delivery Time : 15 working days

Packaging Details : cartons

Stroke (adjustable) : 106/122 mm

Position resolution (fingertip) : ±0.05 mm

Gripper mass : 1-2 kg

Grip force (adjustable) : 10-65 N

Friction grip payload : 1.68 kg

Form-fit grip payload : 1.68 kg

Nominal supply voltage : 24VDC±10%

Full-stroke closing time : 0.7 S

Communication protocol : TCP/IP,USB2.0, RS485,I/O

Contact Now

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

Detailed Images
Production Name DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers
Model PGC-50 robotic clamp device
Application robotic clamp device
Stroke (adjustable) 50 mm
Max payload 2.5 kg
Ingress protection rating IP 67
Grip force (adjustable) 40-140 N
Gripper mass 1kg
Position resolution (fingertip) ± 0.03mm
Nominal supply voltage 24VDC±10%
Full-stroke closing time 0.6 S
Communication protocol TCP/IP, USB2.0, Modbus RTU(RS485), I/O, CAN2.0A,PROFINET,EtherCAT

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-persDH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-persDH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers


China DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers factory

DH-ROBOTICS PGC-140 clamping device matched with UR cobot arm Chinese brand grip-pers Images
